TL60C, RGB Pixel Light Tube

Highlights

RGBWW LED light tube
Manufacturer model: TL60 RGB
Power: 20 W
Color temperature: 2500–10000 K
CRI: 97+

All highlights

Continuous light type: Tube Light
Power: 20 W
Color type: RGB
Color temperature (min): 2500 K
Color temperature (max): 10000 K
Power supply: Battery

All specifications

Length: 60 cm

60 cm 1.2 m

RRP €169.99 incl. VAT

Item number: TL60C
EAN: 6976831830113

Highlights

RGBWW LED light tube
Manufacturer model: TL60 RGB
Power: 20 W
Color temperature: 2500–10000 K
CRI: 97+
TLCI: 98+
Illuminance: 1730 lx at 0.5 m (5600 K)
Dimming: 0–100% in 1% increments
Hue: 0–360°
Saturation: 0–100
Green/magenta correction: -50 to +50
RGBWW channel adjustment: 0–255 per channel
HSI color selection: up to 36,000 colors
Color gel presets: 40 (20 Rosco and 20 LEE)
Pixel sections: 8 individually controllable
Pixel effects: 7
Scene effects: 18
Control: Onboard controls, NEEWER app, 2.4 GHz wireless and DMX512 8-bit
PC control: Via optional NW-BT Bluetooth terminal
Display: Integrated LCD
Mounting thread: 1/4 inch
Beam angle: 180°
Battery: Built-in rechargeable 3000 mAh, 14.8 V, 44.4 Wh
Battery runtime: Up to 120 minutes at full brightness
Power supply: DC or battery
DC input: 20 V / 2.4 A
Dimensions: 42 × 665 mm
Weight: 820 g

The Neewer TL60 RGB light tube is a 20 W RGBWW lighting solution for photography, video production and streaming. Combining red, green, blue, cool white and warm white LEDs, it offers a color temperature range of 2500–10000 K, CRI 97+ and TLCI 98+ for precise color reproduction.

Eight individually controllable pixel sections enable dynamic lighting designs with seven pixel effects and 18 preset scene effects. HSI and RGBCW modes provide detailed color adjustments, while 40 color gel presets expand the creative possibilities.

Lighting settings can be adjusted directly using the onboard controls and LCD screen, through the NEEWER app, via 2.4 GHz wireless control or using DMX512. A separately available NW-BT Bluetooth terminal also enables PC connectivity.

The built-in 3000 mAh rechargeable battery provides up to two hours of operation at full brightness. With a 180° beam angle, a 1/4-inch mounting thread and a weight of 820 g, the TL60 can be integrated into a variety of lighting arrangements.

Technical data

Permanent light

Width	42 mm
Depth	42 mm
Height	662 mm
Weight	820 g
Power	20 W
Brightness control	0% - 100% (1% steps)
Power supply	Battery
Compatible batteries	Integrated battery
Battery capacity	3000 mAh
Max. brightness (0.5 m)	1730 lx
Continuous light type	Tube Light
Number of lights	1 light
Color type	RGB
Color temperature (min)	2500 K
Color temperature (max)	10000 K
Dimming curves	exponential, linear, logarithmic, S
Fan modes	fanless
Color modes	CCT, FX, Picker, RGB, Source Match, Music Sync, HSI, CTO/B
Saturation	adjustable from 1% - 100%
Special features	Color touch panel, Display
Special effects: examples	e.g. fireworks, music sync, thunderstorm
Special effects: quantity	18 special effects
Light control	2.4G radio, App control (Android / IOS), DMX, Touch panel
Number of mountings	1
Mounting types	1/4" thread
Main material	Aluminum alloy
Green/magenta correction	±50
